INFINITY3S-1UR, 1.4 MP USB 3.0 Microscopy Camera CCD
$4,325.00The INFINITY3S-1UR is an ultra-sensitive, low noise CCD camera that offers the speed and accurate color to meet your brightfield imaging requirements, and helps save money by converting into a solution for your routine fluorescence imaging needs
.KEY FEATURES
- Capture still images or videos
- Annotate and measure with ease
- Color camera offers a monochrome mode for routine fluorescence imaging
- Includes software for brightfiled and fluroesence images at no additional cost
- C-mount. Compatible with Leica®, Nikon®, Olympus®, and Zeiss® microscopes
- Windows and Mac compatible
- Color or monochrome ICX825 CCD Global Shutter sensor with 2/3” optical format providing a resolution of 1392 x 1040 using 6.45 x 6.45 μm pixels
- 5.9 e- read noise
- 14-bit pixel depth for 16,384 tonal values per channel
- 60 fps at 1.4 megapixel (monochrome version); 45 fps at 1.4 megapixel (color version)
- High-speed USB 3.0 interface for plug and play installation on any computer
INFINITY5-3, 3.2 Megapixel Global Shutter CMOS Microscope Camera
$3,725.00High performance microscope camera for a wide range of applications – with dual output to HDMI and USB 3
PRODUCT HIGHLIGHTS
- Color or monochrome Sony IMX252 Global Shutter Pregius CMOS sensor with 1/1.8” optical format providing a resolution of 2064 x 1544 with 3.45 x 3.45μm pixels
- Fast frame rates at ~120 fps at full resolution in 8-bit
- Dual output to USB 3 and HDMI compatible monitor
- Intuitive on-camera buttons for power, white balance, and image capture
- Selectable 8 or 12-bit pixel data
- High-speed USB 3.1 Gen 1 interface for fastest image delivery and simplified connectivity. USB 2.0 supported.
- Software is included. Multi-User, Multi-Computer Friendly. No separate licence needed.
- Software compatible with Windows 10, Windows 8.1, Windows 7, 32 and 64-bit operating systems, or MAC OS X 10.12 (or higher)
- Support for third-party capture and analysis applications: Image-Pro by Media Cybernetics, MetaMorph, and Micro-Manager
- Recommended coupler: 0.5x or 0.63x
INFINITY5-5, 5.1 Megapixel Global Shutter CMOS Microscope Camera
$4,275.00High performance microscope camera for a wide range of applications – with dual output to HDMI and USB 3
PRODUCT HIGHLIGHTS
- Sony Pregius global shutter sensor technology
- Color or monochrome IMX250 Global Shutter CMOS sensor with 2/3” optical format providing a resolution of 2464 x 2056 using 3.45 x 3.45μm pixels
- Fast frame rates at ~75 fps at full resolution in 8-bit
- Dual output to USB 3 and HDMI compatible monitor
- Intuitive on-camera buttons for power, white balance, and image capture
- Selectable 8 or 12-bit pixel data
- High-speed USB 3.1 Gen 1 interface for fastest image delivery and simplified connectivity. USB 2.0 supported.
- Software compatible with Windows 10, Windows 8.1, Windows 7, MAC OS X 10.13, 32 and 64-bit operating systems
- Support for third-party capture and analysis applications: Image-Pro by Media Cybernetics, MetaMorph, and Micro-Manager
- Recommended coupler: 0.6x – 0.7x
INFINITY8-2, 1.7 Megapixel USB3 Monochrome Microscope Camera for Fluorescence Imaging
$2,125.00Outstanding Value for Fluorescence Imaging on a Constrained Budget
The INFINITY8-2M is the new go-to microscopy camera for routine fluorescence imaging on a constrained budget. With huge light-gathering pixels, large field of view, and low noise characteristics, this camera enables labs to have a dedicated monochrome camera for their low-light imaging requirements. And, with refresh rates of up to 96 fps at full resolution, the INFINITY8-2M provides exceptional low light sensitivity and allows for accurate imaging, even in variable lighting conditions.
INFINITY8-2M MICROSCOPE CAMERA HIGHLIGHTS
- Monochrome CMOS sensor with 1-inch optical format
- 1.7 megapixel camera with fast frame rates of 96 fps at full resolution (1608 x 1104)
- Direct USB3 interface for fast image delivery and simplified connectivity
- Compact form factor
- Support for locking industrial micro USB on the back for power and control
- INFINITY ANALYZE microscopy software included with purchase. No annual license fees.
- Software support for Windows and Mac, along with third-party plugins for Image-Pro® by Media Cybernetics, MetaMorph, and MicroManager
- Selectable 8 or 12-bit pixel data
- Recommended coupler: 1x
INFINITY8-20, 20 Megapixel Color USB3 Microscope Camera
$4,250.00Ultra High-Resolution Microscope Camera
The ultra high-resolution INFINITY8-20C camera, with a large Field of View, is optimized for fast sample focusing to capture every detail even with low magnification. With no need for pixel shifting or added mechanical movement, the INFINITY8-20C captures images that can be printed at poster sizes. This makes it an ideal choice for biological and material industrial samples.
INFINITY8-20C MICROSCOPE CAMERA HIGHLIGHTS
- Color sensor with 1” optical format
- 20 megapixel microscope camera with fast frame rates of 19.6 fps at full resolution (5472 x 3648)
- USB 3 plug and play interface for fast image delivery and simplified connectivity
- Compact form factor
- Support for locking industrial micro USB on the back for power and control
- INFINITY ANALYZE microscopy software included with purchase. No annual license fees.
- Software support for Windows and Mac, along with third-party plugins for Image-Pro® by Media Cybernetics, MetaMorph, and MicroManager
- Selectable 8 or 12-bit pixel data
INFINITY8-3, 2.9 Megapixel Color/Mono USB3 Microscope Camera
$3,500.00Teledyne Lumenera’s INFINITY8-3 microscopy camera is designed to be a versatile solution for life science, clinical, and material science applications.
Using the Sony® IMX429 global shutter CMOS sensor, with a 2/3” format, this camera is best suited for use with a 0.63x – 0.67x C-mount coupler. It delivers 62 frames per second (fps) at full resolution (1944 x 1472), for rapid response to framing and focusing. With sub-sampling x2 enabled, the full field of view can be acquired at a resolution of 968 x 736, at 124 fps.
PRODUCT HIGHLIGHTS
- 3-megapixels (1944 x 1472), 2/3” format (uses a 0.63X or 0.67X C-mount coupler)
- Sony Pregius global shutter CMOS sensor technology
- 62 frames per second at 1944 x 1472
- 124 frames per second at a resolution of 968 x 736
- True to Life Color Performance, matching what is visible in the eyepieces
- Color performance is optimized for various light sources (LED, Fluorescence, Daylight, Halogen)
- Eliminate frustration with lag-less refresh rates
- Software is included. Multi-User, Multi-Computer Friendly. No separate license needed
- Software compatible with Windows 10, Windows 8.1, Windows 7, 32 and 64-bit operating systems, or MAC OS X 10.15.7 (or greater)
- Support for third-party capture and analysis applications: Image-Pro® by Media Cybernetics, MetaMorph, and MicroManager
