Description
- On-Demand & Batch Printing: Utilize the advanced QRlogix ESPO SLS interface software to easily build fully customizable templates for single-slide or high-volume batch runs.
- Versatile Data Import: Print seamlessly directly from a connected keyboard, live barcode scans, file drops (TXT/CSV via shared folders), or direct spreadsheet imports including Microsoft Excel, CSV, and Google Docs.
- Solvent-Resistant Printing: Utilizing advanced thermal transfer technology, the printed labels stand up permanently to harsh laboratory reagents, including water, alcohol, and xylene.Â
- Integrated Barcode Scanner: Save valuable bench space at your microtomy workstation with a built-in barcode reader that effortlessly pulls data directly to prevent misprints.Â
- Anti-Jam Push Rod Technology: Engineered with a specialized push-rod mechanism instead of traditional gravity-drop layouts to minimize downtime and prevent slide clogs.
| Feature | Specification |
|---|---|
| Brand / Model | Matsunami ESPO Series |
| Printing Technology | High-Resolution Thermal Transfer (~300 dpi) |
| Slide Capacity | Dual 100-slide magazines (200 total capacity) |
| Throughput Speed | Approx. 3 seconds per slide (Up to 20 slides/min) |
| Ejection Modes | Single (1-by-1), Continuous, and Front-Loading |
| Front-Loading Capability | Supports single control slides even with mounted tissue |
| Connectivity | USB, Ethernet (LAN), and Wi-Fi compatible |
| Supported Slide Sizes | 25mm × 75mm × 1mm / 26mm × 76mm × 1mm |
| Weight / Footprint | Ultra-lightweight (~9.9 lbs. / 4.5 kg) for compact bench space |
